It must be placed in the same directory where parkometer.exe is located. This SQL Server database connection string is defined in the configuration file,. Call Parkometer must be configured with a SQL Server database connection string to connect to the pool’s SQL Server. If this tool is run on a remote computer, the SQL Server database used by Lync Server 2013 must be configured to allow remote access. There are no requirements if this tool is run on the same computer that is running CPS. t parameter - tests reserving an orbit in the database to show the randomness of the assigned orbit numbers. Time stamp of when the call was retrieved or dropped. Host name of the CPS where the call was parked. –r parameter-lists the last parked calls.
Microsoft lync 2013 books free#
–f parameter-lists the number of currently free orbits in the pool. Host name of the CPS where the call is parked. SIP Uniform Resource Identifier (URI) of the parkee and parker. –n parameter-lists all currently used orbits in this pool. –o parameter-lists all orbit ranges configured for this pool. This command-line tool provides both read and write-access to the CPS orbit SQL Server database from a local or remotely connected computer.Īll options are mutually exclusive. It also collects statistics about orbits and Call Park Server (CPS) usage. Select a list of regions whose links need to be displayed.Ĭall Parkometer is a tool to track currently parked calls. Select the type or types that need to be displayed.įilter by Region. Select True to enforce the filter.įilter by Link Type. Select True to enforce the filter.įilter by Under utilized.
Select True to enforce the filter.įilter by Critical levels.
Select the list of links that need to be displayed in the graph.įilter by Exceeded limit. The following figures show the previously described filters.įilter by Name. Link type Filter by the following WAN links types: Under-utilized Filter by WAN links whose bandwidth utilization has been less than 25% of the bandwidth capacity R Inter-Region The WAN link between two network regionĮxceeded limit Filter by WAN links whose bandwidth utilization is more than the bandwidth capacityĬritical levels Filter by WAN links whose bandwidth utilization has reached 90% or more than the bandwidth capacity IS Inter-Site The WAN link between two network sites S Site The WAN link from a network site to a network region Name Filter by WAN links (the filter is on the right side of the graph).The prefix denotes the following link types see the vertical (blue) box: The filters that can be applied to the report view as shown below are described as follows: Helps with more effective capacity planning and iteration on the bandwidth capacity that is assigned to various linksīandwidth Utilization Analyzer can generate graphical plots of bandwidth capacity and utilization reports they are as follows:Īll the WAN links in the enterprise networkįiltered by selected WAN links that have been chosenįiltered by WAN links that have exceeded link capacityįiltered by WAN links that have been under-utilizing the provisioned bandwidthįilter by WAN links that have been reaching critical levels (a bandwidth utilization that is greater than 90% of bandwidth capacity of the WAN link)įiltered by WAN link type-network-site links, interregional links, and links within a site Generates specific reports for audio utilization across the network The Bandwidth Utilization Analyzer tool allows an administrator to achieve just that. In any voice and video deployment, it’s critical to monitor and understand the trend of bandwidth utilization of media traffic across the enterprise network. The Restore Defaults option enables administrators to restore Address Book Service settings to default values. It also has options to customize which value of the phone number to be included in the Address Book file. This table has options to map Active Directory Domain Services attributes to the attribute fields for Lync Server 2013 and to specify which users to include or exclude in Address Book Service files based on specific attribute filters. The tool opens to the Configure Attributes tab. The ABSConfig tool can be started by using the absConfig.exe file. To enable administrators to restore default Address Book Service settings. To enable administrators to specify the Active Directory Domain Services attribute to be included or excluded in the Address Book Service files. To enable administrators to map attributes in Active Directory Domain Services to the attributes for Lync Server 2013. The primary scenarios for the tool are the following: ABSConfig is a graphical user interface application that enables administrators to configure Active Directory Domain Services attributes that are related to Address Book Service.
